| Camera |
Image Sensor |
1/1.8″ Progressive Scan CMOS |
|
Max. Resolution |
2560 × 1440 |
|
Min. Illumination |
Color: 0.0001 Lux @ (F1.0, AGC ON) |
|
Shutter Time |
1 s to 1/100,000 s |
|
Day & Night |
IR Cut Filter |
|
Angle Adjustment |
Pan: 0° to 360°; Tilt: 0° to 90°; Rotate: 0° to 360° |
| Lens |
Lens Type |
Fixed Focal Lens, 2.8 mm and 4 mm Optional |
|
Focal Length & FOV |
2.8 mm: Horizontal 104°, Vertical 54.4°, Diagonal 126.7° |
|
Focal Length & FOV |
4 mm: Horizontal 89.3°, Vertical 48.2°, Diagonal 106.5° |
|
Lens Mount |
M16 |
|
Iris Type |
Fixed |
|
Aperture |
F1.0 |
|
Depth of Field |
2.8 mm: 2.5 m to ∞; 4 mm: 2.8 m to ∞ |
| DORI |
2.8 mm |
D: 61 m, O: 24 m, R: 12 m, I: 6 m |
|
4 mm |
D: 68 m, O: 27 m, R: 13 m, I: 6 m |
| Illuminator |
Supplement Light Type |
IR, White Light |
|
Supplement Light Range |
Up to 30 m |
|
Smart Supplement Light |
Yes |
|
IR Wavelength |
850 nm |
| Video |
Main Stream |
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720); 60 Hz: 24 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
|
Sub-Stream |
50 Hz: 25 fps (768 × 432, 640 × 360); 60 Hz: 24 fps (768 × 432, 640 × 360) |
|
Video Compression |
Main Stream: H.265+/H.265/H.264+/H.264; Sub-Stream: H.265/H.264/MJPEG |
|
Video Bit Rate |
32 Kbps to 16 Mbps |
|
H.264 Type |
Baseline Profile, Main Profile, High Profile |
|
H.265 Type |
Main Profile |
|
Bit Rate Control |
CBR, VBR |
|
Region of Interest (ROI) |
1 Fixed Region for Main Stream |
|
Scalable Video Coding (SVC) |
H.264 and H.265 Encoding |
| Audio |
Audio Type |
Mono Sound |
|
Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
|
Audio Bit Rate |
64 Kbps (G.711) / 16 Kbps (G.722.1) / 16 Kbps (G.726) / 32–160 Kbps (MP2L2) / 16–64 Kbps (AAC-LC) |
|
Audio Sampling Rate |
8 kHz / 16 kHz |
|
Environment Noise Filtering |
Yes |
| Network |
Protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IPv4, IPv6, IGMP, UDP, QoS, FTP, SMTP |
|
Simultaneous Live View |
Up to 6 Channels |
|
API |
ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
|
Security |
Password Protection, Complicated Password, Watermark, Basic and Digest Authentication for HTTP, WSSE and Digest Authentication for Open Network Video Interface, Security Audit Log, Host Authentication (MAC Address) |
|
User/Host |
Up to 32 Users; 3 User Levels: Administrator, Operator, User |
|
Client |
iVMS-4200, Hik-Connect |
|
Web Browser |
Plug-in Required Live View: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+; Plug-in-Free Live View: Chrome 80+, Firefox 80+, Edge 89+ |
| Image |
Image Settings |
Rotate Mode, Saturation, Brightness, Contrast, Sharpness, Gain, White Balance; Adjustable by Client Software or Web Browser |
|
Day/Night Switch |
Day, Night, Auto, Schedule |
|
Wide Dynamic Range (WDR) |
120 dB |
|
SNR |
≥ 52 dB |
|
Image Enhancement |
BLC, HLC, 3D DNR |
|
Privacy Mask |
4 Programmable Polygon Privacy Masks |
| Interface |
Ethernet Interface |
1 × RJ45 10 M/100 M Self-Adaptive Ethernet Port |
|
On-Board Storage |
N/A |
|
Built-in Microphone |
Yes, 1 Built-in Microphone |
|
Built-in Speaker |
N/A |
|
Reset Key |
N/A |
| Event |
Basic Event |
Motion Detection (Supports Alarm Triggering by Specified Target Types: Human and Vehicle), Video Tampering Alarm, Exception |
|
Linkage |
Upload to FTP, Notify Surveillance Center, Send Email, Trigger Recording, Trigger Capture |
| General |
Power |
12 VDC ±25%, 0.58 A, Max. 7 W, Ø5.5 mm Coaxial Power Plug, Reverse Polarity Protection |
|
PoE |
IEEE 802.3af, Class 3, Max. 9 W |
|
Material |
Cover: Plastic; Main Body: Metal |
|
Dimension |
69.1 mm × 66.9 mm × 172.9 mm |
|
Package Dimension |
210 mm × 116 mm × 106 mm |
|
Weight |
Approx. 310 g |
|
With Package Weight |
Approx. 465 g |
|
Storage Conditions |
-30°C to 60°C; Humidity 95% or Less (Non-Condensing) |
|
Startup and Operating Conditions |
-30°C to 60°C; Humidity 95% or Less (Non-Condensing) |
|
Language |
English, Russian, Ukrainian, Arabic, Spanish, French, Portuguese, Turkish, Polish, German |
|
General Function |
Heartbeat, Mirror, Flash Log, Password Reset via Email, Password Protection, Anti-Banding |
|
Flashing Light |
N/A |
| Approval |
EMC |
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021 |
|
Safety |
CB: IEC 62368-1:2014+A11; CE-LVD: EN 62368-1:2014/A11:2017 |
|
Environment |
CE-RoHS: 2011/65/EU; WEEE: 2012/19/EU |
|
Protection |
IP67: IEC 60529-2013 |
