| Camera |
Image Sensor |
1/2.8″ Progressive Scan CMOS |
|
Max. Resolution |
1920 × 1080 |
|
Min. Illumination |
Color: 0.001 Lux @ (F1.0, AGC ON); 0 Lux with light |
|
Shutter Time |
1/3 s to 1/100,000 s |
|
Day & Night |
IR Cut Filter |
|
Angle Adjustment |
Pan: 0° to 360°; Tilt: 0° to 75°; Rotate: 0° to 360° |
| Lens |
Lens Type |
Fixed Focal Lens, 2.8 mm and 4 mm Optional |
|
Focal Length & FOV |
2.8 mm: Horizontal 106°, Vertical 56°, Diagonal 129° |
|
Focal Length & FOV |
4 mm: Horizontal 88°, Vertical 47°, Diagonal 103° |
|
Lens Mount |
M12 |
|
Iris Type |
Fixed |
|
Aperture |
F1.0 |
| DORI |
2.8 mm |
D: 44 m, O: 17 m, R: 8 m, I: 4 m |
|
4 mm |
D: 53 m, O: 21 m, R: 10 m, I: 5 m |
| Illuminator |
Supplement Light Type |
IR, White Light |
|
Supplement Light Range |
Up to 30 m |
|
Smart Supplement Light |
Yes |
|
IR Wavelength |
850 nm |
| Video |
Main Stream |
50 Hz: 25 fps (1920 × 1080, 1280 × 720); 60 Hz: 30 fps (1920 × 1080, 1280 × 720) |
|
Sub-Stream |
50 Hz: 25 fps (640 × 480, 640 × 360); 60 Hz: 30 fps (640 × 480, 640 × 360) |
|
Video Compression |
Main Stream: H.265+/H.265/H.264+/H.264; Sub-Stream: H.265/H.264/MJPEG |
|
Video Bit Rate |
32 Kbps to 8 Mbps |
|
H.264 Type |
Baseline Profile, Main Profile, High Profile |
|
H.265 Type |
Main Profile |
|
Bit Rate Control |
CBR, VBR |
|
Region of Interest (ROI) |
1 Fixed Region for Main Stream |
| Audio |
Audio Type |
Mono Sound |
|
Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC |
|
Audio Bit Rate |
64 Kbps (G.711) / 16 Kbps (G.722.1) / 16 Kbps (G.726) / 32–160 Kbps (MP2L2) / 16–64 Kbps (AAC-LC) |
|
Audio Sampling Rate |
8 kHz / 16 kHz |
|
Environment Noise Filtering |
Yes |
| Network |
Protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, UDP, QoS, FTP, SMTP, UPnP |
|
Simultaneous Live View |
Up to 6 Channels |
|
API |
Open Network Video Interface (Profile S, Profile T, Profile G only -F model), ISAPI, SDK |
|
Security |
Password Protection, Complicated Password, Watermark, Basic and Digest Authentication for HTTP, WSSE and Digest Authentication for Open Network Video Interface, Security Audit Log, Host Authentication (MAC Address) |
|
User/Host |
Up to 32 Users; 3 User Levels: Administrator, Operator, User |
|
Client |
iVMS-4200, Hik-Connect |
|
Web Browser |
Plug-in Required Live View: IE 10, IE 11; Local Service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Image |
Image Settings |
Rotate Mode, Saturation, Brightness, Contrast, Sharpness, Gain, White Balance; Adjustable by Client Software or Web Browser |
|
Day/Night Switch |
Day, Night, Auto, Schedule |
|
Wide Dynamic Range (WDR) |
Digital WDR |
|
SNR |
≥ 52 dB |
|
Image Enhancement |
BLC, HLC, 3D DNR |
|
Privacy Mask |
4 Programmable Polygon Privacy Masks |
| Interface |
Ethernet Interface |
1 × RJ45 10 M/100 M Self-A |
