Description
| Specifications | |
|---|---|
| General | |
| Model | XFX AMD Radeon™ AI PRO R9700 |
| Architecture | AMD RDNA™ 4 |
| Graphics Processor | Navi 48 |
| Bus Interface | PCI Express 5.0 x16 |
| Form Factor | Dual-Slot |
| Cooling Solution | Blower Fan |
| GPU Specifications | |
| Compute Units | 64 |
| Stream Processors | 4,096 |
| AI Accelerators | 128 |
| Ray Accelerators | 64 |
| Base Clock | Up to 1,620 MHz |
| Game Clock | Up to 2,350 MHz |
| Boost Clock | Up to 2,920 MHz |
| Memory | |
| Memory Size | 32GB GDDR6 |
| Memory Bus | 256-bit |
| Memory Speed | 20 Gbps |
| Memory Bandwidth | Up to 640 GB/s |
| Infinity Cache | 64 MB |
| ECC Support | Yes (Linux Only) |
| AI & Compute Performance | |
| FP32 Performance | Up to 47.8 TFLOPS |
| FP16 Matrix Performance | Up to 191 TFLOPS |
| INT8 AI Performance | Up to 383 TOPS (766 TOPS with Structured Sparsity) |
| INT4 AI Performance | Up to 766 TOPS (1,531 TOPS with Structured Sparsity) |
| Display Outputs | |
| DisplayPort | 4 × DisplayPort 2.1a |
| Maximum Displays | Up to 4 Displays |
| Power Requirements | |
| Total Board Power (TBP) | 300W |
| Power Connector | 1 × 12V-2×6 |
| Recommended PSU | 750W or Higher |
| Supported Operating Systems | |
| Windows | Windows 10 64-bit / Windows 11 64-bit |
| Linux | Linux x86 64-bit |
| Key Features | |
| Professional Workloads | AI Inference, Machine Learning, Generative AI, 3D Rendering, CAD, Scientific Computing, Content Creation |
| Multi-GPU Support | PCIe Gen 5 Scalable Workstation Support |
| Hardware Encoding/Decoding | AMD Media Engine with AV1, H.264, and H.265 Support |
| AMD Technologies | AMD RDNA™ 4, AMD Infinity Cache, AMD AI Accelerators, AMD ROCm™ Support |
