Description
| Specification | Details |
|---|---|
| Graphics Engine | AMD Radeon™ RX 9070 XT |
| Model Name | RX9070XT 16G-L/OC/WHITE |
| Series | Hellhound |
| Stream Processor | 4096 Units |
| Video Memory | 16GB GDDR6 |
| Memory Speed | 20.0 Gbps |
| Memory Interface | 256-bit |
| Engine Clock (OC) | Up to 2460MHz (Game)¹ / Up to 3010MHz (Boost)² |
| Engine Clock (STD/Silent) | Up to 2400MHz (Game)¹ / Up to 2970MHz (Boost)² |
| Bus Standard | PCIe 5.0 x16 |
| Standard Display Connectors | 1 × HDMI 2.1b, 3 × DisplayPort 2.1a |
| DirectX® Support | 12 |
| OpenGL | 4.6 |
| AMD Eyefinity Technology | Support |
| AMD Stream Technology | Support |
| AMD Smart Access Memory | Support |
| Maximum Resolution (DisplayPort) | 7680 × 4320 |
| Maximum Resolution (HDMI) | 7680 × 4320 |
| Board Dimensions | 327mm × 128mm × 49mm |
| Board Dimensions (with Bracket) | 340mm × 142mm × 49mm |
| Slot | 2.5 |
| Minimum System Power Requirement | 800W |
| Extension Power Connector | Two 8-pin PCI Express Power Connectors |
