Description
| LCD SCREENÂ | |
| System Requirement | Â Windows 10, Windows 11 |
| Dimension | Â 2.1 inch |
| Resolution | Â 480×480 |
| Backlight |  600cd/m² |
| Color | Â 24-bit, 16.7 million |
|
Compatibility |
 Intel LGA2066/2011/1851/1700/1200/1151/1150/1155/1156 |
|
 AMD AM5/AM4 |
|
|
TDP |
 350W |
|
Radiator Dimension |
 397×120×27mm |
|
Radiator Material |
 Aluminum |
|
Tube Material |
 Premium Sleeved Tubing |
|
Tube Length |
 465mm |
|
Waterblock Dimension |
 76x76x58mm |
|
Cold Plate Material |
 Copper |
|
Pump Current |
 0.36A Max. |
|
Pump Speed |
 2500RPM±10% |
|
Pump Bearing |
 Ceramic Bearing |
|
Pump Life Expectancy |
 50,000 Hrs |
|
Pump Noise Level |
 25dB(A) |
|
Fan Dimension |
 120×120×25mm |
|
Included Fans |
 3pcs |
|
Fan Speed |
 500～1800±10%RPM |
|
Max. Air Flow |
 76.16CFM |
|
Max. Static Pressure |
 2.16mmH2O |
|
Noise |
 35.2dB(A) Max. |
|
Rated Voltage |
 12VDC |
|
Operating Voltage |
 10.8～13.2VDC |
|
Started Voltage |
 7VDC |
|
Rated Current |
 0.2A |
|
Power Input |
 2.4W |
|
Bearing Type |
 Hydraulic Bearing |
|
Connector |
 4Pin PWM/5V 3Pin ARGB |
