Description
| Specification | Details |
|---|---|
| Product Name | Vertical Graphics Card Holder Kit V3 PCIe 5.0 x16 165mm |
| Color | Black / White |
| Model Number | Black: MCA-U000C-KFVK03 White: MCA-U000C-WFVK03 |
| Dimensions (L × W × H) | GFX Holder Kit: 249 × 148.1 × 141.8 mm (Closed) 305 × 178.1 × 141.8 mm (Open) Riser Cable: 165 mm |
| Supported Chassis Type | E-ATX, ATX, Micro ATX May interfere with rear-panel component installation. Max. CPU cooler height: 70 mm |
| Supported Graphics Cards | Any length, up to 3 slots wide |
| Component Materials | PCBA, Silver-Plated Copper Wire 30 AWG |
| Insulation Materials | FEP (Cable), PA10T + 35% GF (Connector) |
| Other Materials | ABS, PP, SGCC Steel, Nickel, Gold, Brass |
| Compatibility | PCIe 5.0 and older versions |
| CE Certification Number | BKC25093934JC |
| PCB / Wire UL Numbers | E467745 / E527405 |
| Connectors | PCIe x16 Male to PCIe x16 90° Female |
| Required PCI Slots | Minimum 4 PCI slots required for mounting |
| Working Voltage / Current | DC 12V / 3.3V / 3.3Vaux, 75W (Max.) |
| Operating Temperature | -20°C to +80°C |
| Net Weight | 0.81 kg |
| Gross Weight | 1.03 kg |
