Description
| Specification | Details |
|---|---|
| Model Number | Black: E690-KHNN-S00 |
| Color | Black |
| Front Panel Material | Tempered Glass + Wood |
| Left Side Panel Material | Tempered Glass |
| Right Side Panel Material | Steel |
| Dimensions (L × W × H) | 434 × 218 × 454 mm (Incl. Protrusions) / 430 × 218 × 435 mm (Excl. Protrusions) |
| Volume | 42.93 L (Incl. Protrusions) |
| Motherboard Support | ITX / Micro-ATX / ATX |
| Expansion Slots | 7 |
| 5.25″ Drive Bays | 0 |
| 3.5″ Drive Bays | 1 (Max. 2) |
| 2.5″ Drive Bays | 1 (Max. 2) |
| I/O USB Ports | 1 × USB Type-C 20Gbps / 2 × USB 3.0 |
| I/O Audio | 1 × 3.5mm Combo |
| Rear Fan | 1 × 120mm ARGB PWM |
| Side Fans | 2 × 120mm ARGB PWM Reverse Fans |
| Top Fan Support | 2 × 140mm / 3 × 120mm |
| Rear Fan Support | 1 × 120mm |
| Side Fan Support | 2 × 120mm |
| Bottom Fan Support | 3 × 120mm |
| Top Radiator Support | 120 / 240 / 360mm (Max. Height: 45mm) |
| Bottom Radiator Support | 120 / 240 / 360mm |
| Side Radiator Support | 120 / 240mm |
| CPU Cooler Clearance | 170mm |
| PSU Clearance | 250mm |
| Graphics Card Clearance | 425mm |
| Power Supply Support | ATX |
| Series | Elite Series |
