Description
| Print Head/Consumables | |
| Number of Nozzles | Total 1,280 nozzles |
| Ink Cartridges (Type/Colours) | PG-745S (Pigment Ink/Black), CL-746S (Dye-Based Ink/Colour) [Optional: PG-746, CL-746 / PG-745XL, CL-746XL] |
| Maximum Print Resolution | 4,800 (horizontal)*1 x 1,200 (vertical) dpi |
| Print Speed*2 (Approx.)
Click here for summary report |
|
| Document (ESAT/Simplex) | 7.7 / 4.0 ipm (mono/colour) |
| Photo (4 x 6″) (PP-201/Borderless) | 65 sec |
| Print Width | Up to 203.2 mm (8″) |
| Recommended Printing Area | Top margin: 31.6 mm Bottom margin: 29.2 mm |
Paper Handling
| Print Margin | |
| Borderless Printing*3 | Top/Bottom/Left/Right margin: 0 mm |
| Bordered Printing | LTR: Left margin: 6.4 mm Right margin: 6.3 mm Others: |
| Supported Media | |
| Rear Tray | Plain Paper (64 – 105 g/m2) Photo Paper Plus Glossy II (PP-201, PP-208) |
| Paper Size | |
| Rear Tray | A4, LTR, 4 x 6″, 5 x 7″
[Custom Size] *F4 is possible via custom size settings. |
| Borderless Printing*3 | 4 x 6″ |
| Maximum Capacity | Plain Paper, 64 g/m² (A4, LTR): 60 Photo Paper Plus Glossy II (PP-201, PP-208, 4 x 6″): 20 Photo Sticker (PS-208): 1 |
| Paper Weight | |
| Rear Tray | Plain Paper: 64 – 105 g/m² Canon Paper: Approx. 275 g/m² (Max.) (Photo Paper Plus Glossy II, PP-201) |
Printing Solutions
| Canon Printing Apps | |
| Others | Easy-PhotoPrint Editor, PosterArtist Lite, PosterArtist (Web) |
System Requirements
| OS System Compatibility*4 | Windows 10 / 8.1 / 7 SP1 macOS 10.12*5 or later |
General Specifications
| Interface | USB 2.0 |
| Operating Environment*6 | |
| Temperature | 5 – 35°C |
| Humidity | 10 – 90% RH (no dew condensation) |
| Recommended Environment*7 | |
| Temperature | 15 – 30°C |
| Humidity | 10 – 80% RH (no dew condensation) |
| Storage Environment | |
| Temperature | 0 – 40°C |
| Humidity | 5 – 95% RH (no dew condensation) |
| Quiet Mode | Available |
| Acoustic Noise*8 (PC Print) | |
| Photo (4 x 6”) | 46 dB(A) |
| Power Requirements | AC 100 – 240 V, 50/60 Hz |
| Power Consumption (Approx.) | |
| OFF | 0.2 W |
| Standby | 2.1 W |
| Operation*9 | 10 W |
| Dimensions (W x D x H) | |
| Factory Configuration | 426 x 255 x 131 mm |
| Output/ADF Trays Extended | 426 x 562 x 213 mm |
| Weight | 2.5 kg |
Page Yield*10
| Plain Paper Click here for more information |
A4 Colour Documents*11: PG-745S / CL-746S: 100 Optional: |
| Photo Paper (PP-201) Click here for more information |
4 x 6 Photos*12: PG-745S: 835*13 CL-746S: 32 Optional: |
