Description
| Input Voltage | 230VAC |
| Frequency | 50hz – 60hz (auto sensing) |
| Voltage Range | 170 – 280VAC |
| Capacity VA/Wattage | 850VA AIO/595W |
| Transfer Time | 2 – 6 ms (typical) 12 ms (max) |
| Outlet Socket | back-up x4 / bypass x4, total of 8 sockets |
| Plug & Socket | NEMA 5-15p to C13 plug, IEC C14 input socket & NEMA 5-15r output socket |
| Back up time | 6 – 30mins depending on computer load |
| Wave Form | Pure Sine Wave under main mode, Simulated Sine Wave under battery mode |
| Protection | Full Protection: Discharge, overcharge and overload protection. |
| Indicator | AC mode: Green LED Light Battery Mode: Yellow LED Flashing Fault Mode: Red LED Light |
| Audible Alarm | Backup mode: sounding every 10secs Low Battery: sounding every 1sec Overload : sounding every 0.5sec Fault: continuous sound |
| Noise Level | less than 45dB |
| Battery | 12V/7Ahx1 Type. Sealed lead acid maintenance-free. Protection. Auto-inspection, discharge protection and battery fault caution. Battery. Normally, battery is charge once in three months. |
| Recharge Time | Typical 6 – 8hrs to 90% after complete discharge |
| Dimension | L293 x W202 x H93 mm |
| Mounting | Flat surface & Wall mountable |
