Description
| Input Voltage | 230VAC |
| Frequency | 50hz – 60hz (auto sensing) |
| Voltage Range | 140 – 300VAC |
| Capacity VA/Wattage | 3KVA/2100W |
| Transfer Time | 4 – 8 ms (typical) |
| Power Cord Length | 1.2meter |
| Outlet Socket | back-up x6, bypass x2, total of 8 sockets |
| Plug & Socket | NEMA 5-15p & NEMA 5-15r |
| Back up time | 6 – 30mins depending on computer load |
| Topology | Line-interactive with Built-in AVR |
| Wave Form | Pure Sine Wave under main mode, Simulated Sine Wave under battery mode |
| Protection | Overload: As load over 130%, UPS is protected in 3seconds. Load input: Fuse for overload and short circuit protection. Short Circuit: UPS cut off immediately. |
| Indicator | AC mode: LCD Battery Mode: LCD Fault Mode: LCD |
| Audible Alarm | Backup mode: sounding every 10secs Low Battery: sounding every 1sec Overload : sounding every 0.5sec Fault: continuous sound |
| Noise Level | less than 45-55dB |
| Battery | 12V/9Ahx2 Type. Sealed lead acid maintenance-free. Protection. Auto-inspection, discharge protection and battery fault caution. Battery. Normally, battery is charge once in three months. |
| Recharge Time | Typical 9 – 10hrs |
| Dimension | L353 x W149 x H162 mm |
| Weight (kg) | GW: 8.90kgs NW: 8.45kgs |
