Description
| SPECIFICATIONS | ||
| Form Factor | M.2 | |
|---|---|---|
| Capacity | 1TB | |
| Sequential Read Speed | Up to 7,250 MB/s | |
| Sequential Write Speed | Up to 6,300 MB/s | |
| GENERAL FEATURE | ||
| Application | Client PCs | |
|---|---|---|
| Form Factor | M.2 (2280) | |
| Interface | PCIe® Gen 4.0 x4 / 5.0 x2 NVMe™ 2.0 | |
| Dimension (WxHxD) | 80.15 x 22.15 x 2.38mm | |
| Weight | Max 9.0g Weight | |
| Storage Memory | Samsung V-NAND TLC | |
| Controller | Samsung in-house Controller | |
| Cache Memory | HMB(Host Memory Buffer) | |
| SPECIAL FEATURE | ||
| Trim Support | Supported | |
|---|---|---|
| S.M.A.R.T Support | Supported | |
| GC (Garbage Collection) | Auto Garbage Collection Algorithm | |
| Encryption Support | AES 256-bit Encryption (Class 0) TCG/Opal IEEE1667 (Encrypted drive) |
|
| WWN Support | Not supported | |
| Device Sleep Mode Support | Yes | |
| ENVIRONMENT | ||
| Average Power Consumption (System Level) | Average: Read 4.3 W / Write 4.2 W | |
|---|---|---|
| Power Consumption (Idle) | Typical 60 mW | |
| Power Consumption (Device Sleep) | Typical 5mW | |
| Average Voltage | 3.3 V ± 5 % Allowable voltage | |
| Reliability (MBTF) | 1.5 Million Hours Reliability (MTBF) | |
| Operating Temperature | 0 – 70 ℃ Operating Temperature | |
| Shock | 1,500 G & 0.5 ms (Half sine) | |
| SOFTWARE | ||
| Management SW | Magician Software for SSD management | |
|---|---|---|
