RAMSTA RS-A320MP AMD Motherboard | AM4 DDR4

Brands:

1,900.00

Availability: In Stock
Brand Ramsta
Model RS-A320MP
CPU Socket Supports AMD AM4 Ryzen Series CPU Socket
Chipset Type AMD A320
RAM Memory Technology 2 x DDR4 DIMM Slots
Wireless Communication Module N/A
Form Factor Micro ATX



Description

SPECIFICATIONS

CPU Supports AMD Socket AM4 Ryzen Series CPU
Chipset AMD A320
Memory
  • 2*288-pin DDR4 SDRAM Slots
  • Memory up to 32GB
  • Supports dual-channel DDR4 2133MHz-3000MHz memory
BIOS AMI EFI-BIOS
I/O Interface
  • 1x VGA Port
  • 1x HDMI Port
  • 4x USB 2.0 compatible with USB 1.0
  • 2x USB 3.0 Port
  • 1x RJ45 Port
  • 1x 3-in-1 Audio Port (Line In / Line Out / Mic In)
Onboard Interface
  • 1x 24-pin ATX Power Connector
  • 1x 4-pin ATX 12V Power Connector
  • 1x USB Connectors, can support 2*USB 2.0
  • 1x F _Audio Connector
  • 1x F _Panel Connector
  • 1x Speaker Connector
  • 2x Fan Connectors
  • 4x Serial ATA Connection Port
  • 1x COM Connector
Integrated Sound
  • with 6-channel HD Audio Code Onboard
  • provides front audio and stereo mic interface
Integrated LAN with 100/4000Mbps LAN onboard
Expansion Slot
  • 1x PCI Express x16 Slot
  • 1x PCI Express x1 slot (NVMe M.2)
  • 1x M.2 Slot
FORM FACTOR  Micro ATX (22cm x 20cm)
