Description
SPECIFICATIONS
| MAIN SPEC |
| Graphics Engine |
AMD Radeonâ„¢ RX 7900 XTX |
| Series |
Hellhound |
| Stream Processor |
6144 Units |
| Video Memory |
24GB GDDR6 |
| Memory Speed |
20.0 Gbps |
| Memory Interface |
384-bit |
| Engine Clock(OC) |
up to 2330MHz(Game)¹
up to 2525MHz(Boost)² |
| Engine Clock(STD/Silent) |
up to 2270MHz(Game)¹
up to 2500MHz(Boost)² |
| Bus Standard |
PCIE 4.0 |
| Standard Display Connectors |
1 x HDMI 2.1，3 x DisplayPort 2.1 (only 2x simultaneous DP2.1 connections can be supported) |
|
| FEATURE SUPPORT |
| DirectX® Support |
12 |
| OpenGL |
4.6 |
| AMD Eyefinity Technology |
Support |
| AMD Stream Technology |
Support |
| AMD Smart Access Memory |
Support |
|
| MAXIMUM RESOLUTION |
| DisplayPort |
7680×4320 |
| HDMI |
7680×4320 |
|
| POWER SPECS + BOARD DIMENSIONS |
| Board Dimensions |
320mm*118.5mm*62mm
338mm*147mm*62mm(with bracket) |
| Slot |
3 |
| Minimum System Power requirement (W) |
800W³ |
| Extension Power Connector |
Two 8-pin PCI Express Power connectors |
|
Remarks:
¹Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
²Boost Clock is the maximum frequency achievable on the GPU running a burstyworkload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to:thermal conditions and variation in applications and workloads.
³Recommended power supply for AMD Radeon RX 7900 XTX graphics card is minimum 800W or greater power supply with 12V output > 65A. Minimum recommended system power supply wattage is based on a PC configured with an AMD Ryzen 9 5900X processor plus typical power requirements of other system components. Your system requirements may differ.
