Description
| Interface | 2 * 100Mbps POE Port + 1 * 100Mbps Input Port |
| Basic function | IEEE 802.3 Ethernet and IEEE802.3u Fast Ethernet protocol standards Compatible with PDs compliant with IEEE 802.3af/at standard Compatible with certified non-standard PD Store and Forward MAC auto learning and aging IEEE 802.3X full-duplex flow control and Backpressure half-duplex flow control |
| Standards | IIEEE 802.3 Ethernet Media Access Control Protocol IEEE 802.3i 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3af enables powering Ethernet devices through Ethernet data pairs or devices IEEE 802.3at realizes high-power power supply for Ethernet devices through Ethernet data wire pairs or devices IEEE 802.3x flow control |
| Mode | OFF (Default mode) ON (Extended mode) |
| Data Transfer Rate | Ethernet 10Mbps half duplex, 20Mbps full duplex Fast Ethernet 100Mbps half duplex, 200Mbps full duplex |
| Store & Forwarding | Yes |
| Switching Capacity | 0.6G |
| MAC Address Table Size | 2K |
| Power | Supports standard POE, IEEE 802.3at to receive power, 30W max |
| Environment | Operation Temperature：0℃～40℃ Storage Temperature：-40℃～70℃ Operation Humidity：10%～90% RH Non-condensing Storage Humidity：5%～90% RH Non-condensing |
| Cabling type | 100Base-TX: Cat 5e or better UTP/STP(≤100m) 10Base-TX: Cat 5e or better UTP/STP(≤250m) |
| Dimensions(L *Â W *Â H ) | 150*98*36.5mm |
