SPECIFICATIONS
Essentials | |
Product Collection | Intel® Arc™ B-Series Graphics |
Model Number | B580 |
Code Name | Products formerly Battlemage |
Microarchitecture | Xe2 |
Lithography Type | TSMC N5 |
Vertical Segment | Desktop |
Marketing Status | Launched |
Launch Date | Q4’24 |
Embedded Options Available | No |
GPU Specifications | |
Xe-cores | 20 |
Render Slices | 5 |
Ray Tracing Units | 20 |
Intel® Xe Matrix Extensions (Intel® XMX) Engines | 160 |
Xe Vector Engines | 160 |
Graphics Clock | 2670 MHz |
GPU Peak TOPS (Int8) | 233 |
TBP | 190 W |
PCI Express Configurations ‡ | PCI Express 4.0 x8 |
Device ID | 0xE20B |
Memory Specifications | |
Memory | 12 GB GDDR6 |
Graphics Memory Interface | 192 bit |
Graphics Memory Bandwidth | 456 GB/s |
Graphics Memory Speed | 19 Gbps |
I/O Specifications | |
# of Displays Supported‡ | 4 |
Graphics Output‡ | HDMI* 2.1 |  DP2.1 up to UHBR 13.5 |  DP2.1 up to UHBR 10 |
HDMI Variable Refresh Rate (VRR) | Yes |
VESA Adaptive Sync | Yes |
Media Profiles | HDR10 |Â Â HDR10+ Gaming |Â Â Dolby Vision |
Max Resolution (HDMI)‡ | 7680 x 4320@120Hz |
Max Resolution (DP)‡ | 7680 x 4320@60Hz |
Features | |
H.264 Hardware Encode/Decode | Yes |
H.265 (HEVC) Hardware Encode/Decode | Yes |
AV1 Encode/Decode | Yes |
VP9 Bitstream & Decoding | Yes |
Supported Technologies | |
Ray Tracing | Yes |
oneAPI Support | Yes |
OpenVINOâ„¢ Support | Yes |
DirectX* Support | DirectX 12 Ultimate |
Vulkan*Â Â Support | 1.3 |
OpenGL* Support | Up to 4.6 |
OpenCL* Support | 3 |
Multi-Format Codec Engines | 2 |
Intel® Extension for PyTorch* (IPEX) Support | Yes |
Intel® Xe Super Sampling (XeSS) Support | Yes |
Intel Reference Card Attributes | |
Dimensions (Length x Width) | 272 x 115 mm |
Slots | 2 |
Weight | 779 G |
Minimum Power Supply Unit | 600 W |
Power Connectors | 1 x 8-pin |
