| Intelligent Analytics |
AI by Device |
Perimeter Protection, Motion Detection 2.0; Facial Recognition, Perimeter Protection, Motion Detection 2.0 |
|
AI by Camera |
Perimeter Protection, Throwing Objects from Building, Motion Detection 2.0, ANPR, VCA; Facial Recognition, Perimeter Protection, Throwing Objects from Building, Motion Detection 2.0, ANPR, VCA |
| Perimeter Protection |
By Device |
1-ch, 4 MP (HD Network Camera, H.264/H.265) Video Analysis for Human and Vehicle Recognition to Reduce False Alarm |
|
By Camera |
All Channels |
| Throwing Objects from Building |
By Camera |
All Channels |
| Target Recognition |
Facial Detection and Analytics |
Face Picture Comparison, Human Face Capture, Face Picture Search; N/A |
|
Face Picture Library |
Up to 16 Face Picture Libraries, with up to 20,000 Face Pictures in Total (Each Picture ≤ 4 MB, Total Capacity ≤ 1 GB) |
|
Facial Detection and Analytics Performance |
1-ch, 8 MP |
|
Face Picture Comparison |
4-ch |
| Motion Detection 2.0 |
By Device |
1-ch, 4 MP (HD Network Camera, H.264/H.265) Video Analysis for Human and Vehicle Recognition to Reduce False Alarm; 4-ch, 4 MP (when Enhanced SVC Mode is Enabled, up to 8 MP) Video Analysis for Human and Vehicle Recognition to Reduce False Alarm; All Channels, 4 MP (when Enhanced SVC Mode is Enabled, up to 8 MP) Video Analysis for Human and Vehicle Recognition to Reduce False Alarm |
|
By Camera |
All Channels |
| Video and Audio |
IP Video Input |
8-ch |
|
Incoming Bandwidth |
80 Mbps |
|
Outgoing Bandwidth |
80 Mbps |
|
HDMI Output |
1-ch, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz |
|
VGA Output |
1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz |
|
Video Output Mode |
HDMI/VGA Simultaneous Output; HDMI/VGA Independent Output |
|
CVBS Output |
N/A |
|
Audio Output |
1-ch, RCA (Linear, 1 KΩ) |
|
Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1 KΩ, Using the Audio Input) |
| Decoding |
Decoding Format |
H.265/H.265+/H.264+/H.264 |
|
Recording Resolution |
12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
|
Synchronous Playback |
8-ch |
|
Decoding Capability (AI On) |
1-ch @ 12 MP (30 fps); 1-ch @ 8 MP (30 fps); 3-ch @ 4 MP (30 fps); 6-ch @ 1080p (30 fps) |
|
Decoding Capability (AI Off) |
1-ch @ 12 MP (30 fps); 2-ch @ 8 MP (30 fps); 4-ch @ 4 MP (30 fps); 8-ch @ 1080p (30 fps) |
|
Stream Type |
Video, Video & Audio |
|
Audio Compression |
G.711ulaw/G.711alaw/G.722/G.726/AAC |
| Network |
Remote Connection |
128 |
|
API |
ONVIF (Profile S/G); SDK; ISAPI |
|
Compatible Browser |
IE11, Chrome V57, Firefox V52, Safari V12, Edge V89 or Above |
|
Network Protocol |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnPâ„¢, HTTP, HTTPS |
|
Network Interface |
1 × RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface; 1 × RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
| PoE |
Interface |
8 × RJ-45 10/100 Mbps Self-Adaptive Ethernet Interfaces |
|
Power |
≤ 75 W |
|
Standard |
IEEE 802.3af/at |
| Auxiliary Interface |
SATA |
1 × SATA Interface |
|
Capacity |
Up to 10 TB Capacity for Each HDD |
|
USB Interface |
Front Panel: 1 × USB 2.0; Rear Panel: 1 × USB 2.0 |
|
Alarm In/Out |
4/1; N/A; N/A; N/A (4/1 is Optional) |
| General |
GUI Language |
English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz, Brazilian Portuguese, Indonesian |
|
Power Supply |
48 VDC, 1.875 A |
|
Consumption |
≤ 10 W (Without HDD and PoE Off) |
|
Working Temperature |
-10°C to 55°C (14°F to 131°F) |
|
Working Humidity |
10% to 90% |
|
Dimension (W × D × H) |
320 mm × 240 mm × 48 mm (12.6″ × 9.4″ × 1.9″) |
|
Weight |
≤ 1 kg (Without HDD, 2.2 lb.) |
| Certification |
FCC |
Part 15 Subpart B, ANSI C63.4-2014 |
|
CE |
EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035:2017 |
|
Obtained Certification |
CE, FCC, IC, CB, KC, UL, RoHS, REACH, WEEE, RCM, UKCA, LOA, BIS |
