Description
Intelligent Analytics
| Feature | Specification |
|---|---|
| AI by NVR | Facial Recognition, Perimeter Protection, Motion Detection 2.0, AcuSearch, AcuSeek |
| AI by Camera | Facial Recognition, Perimeter Protection, Motion Detection 2.0, ANPR, VCA |
| AcuSearch | By Camera: All channels. The camera must support and have AcuSearch enabled. |
| AcuSeek Performance | Supports AcuSeek on all channels when cameras support Hikvision AcuSense technology and have AcuSearch enabled. Capable of modeling up to 50,000 targets per day. |
| Search Language | English |
| Perimeter Protection by NVR | Video analysis for human and vehicle recognition using HD network cameras with H.264/H.265 compression to reduce false alarms. Up to 2 channels at 4 MP; 1 channel at 5 MP to 8 MP. |
| Perimeter Protection by Camera | All channels |
| Facial Detection and Analytics | Face picture comparison, human face capture, and face picture search |
| Face Picture Library | Up to 16 face picture libraries, with up to 50,000 face pictures in total. Each picture: ≤ 1 MB; total capacity: ≤ 800 MB |
| Facial Detection and Analytics Performance | Up to 2 channels at 4 MP; 1 channel at 5 MP to 8 MP |
| Face Picture Comparison | 8 channels |
| Motion Detection 2.0 by NVR | All channels; up to 4 MP for human and vehicle recognition to reduce false alarms. Supports up to 8 MP when Enhanced SVC mode is enabled. |
| Motion Detection 2.0 by Camera | All channels |
Video and Audio
| Feature | Specification |
|---|---|
| IP Video Input | 16 channels |
| Incoming Bandwidth | 160 Mbps |
| IP Speaker Input | 4 channels |
| Outgoing Bandwidth | 160 Mbps |
| HDMI Output | 1 channel; 4K (3840 × 2160) at 30 Hz, 2K (2560 × 1440) at 60 Hz, 1920 × 1080 at 60 Hz, 1600 × 1200 at 60 Hz, 1280 × 1024 at 60 Hz, 1280 × 720 at 60 Hz |
| VGA Output | 1 channel; 1920 × 1080 at 60 Hz, 1600 × 1200 at 60 Hz, 1280 × 1024 at 60 Hz, 1280 × 720 at 60 Hz |
| Video Output Mode | Independent HDMI/VGA output |
| CVBS Output | N/A |
| Audio Output | 1 channel, RCA (linear, 1 kΩ) |
| Two-Way Audio | 1 channel, RCA (2.0 Vp-p, 1 kΩ, using the audio input) |
Decoding
| Feature | Specification |
|---|---|
| Decoding Format | H.265, H.265+, H.264, H.264+ |
| Recording Resolution | 12 MP, 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF |
| Synchronous Playback | 16 channels |
| Decoding Capability (AI On) | 2-channel 12 MP at 30 fps; 3-channel 8 MP at 30 fps; 4-channel 6 MP at 30 fps; 6-channel 4 MP at 30 fps; 8-channel 3 MP at 30 fps; 12-channel 2 MP at 30 fps |
| Decoding Capability (AI Off) | 4-channel 12 MP at 30 fps; 6-channel 8 MP at 30 fps; 8-channel 6 MP at 30 fps; 12-channel 4 MP at 30 fps; 16-channel 3 MP at 30 fps; 16-channel 2 MP at 30 fps |
| Stream Type | Video; Video and Audio |
| Live View Window Division | 1, 2, 4, 6, 8, 9, 16 |
| Playback Mode | Normal, Smart, Event, Tag, External File |
| Audio Compression | G.711 μ-law, G.711 A-law, G.722, G.726, AAC, MP2L2 |
Network
| Feature | Specification |
|---|---|
| Remote Connections | 128 |
| API | ONVIF (Profile S/G), SDK, ISAPI |
| Network Protocols | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnPâ„¢, HTTP, HTTPS |
| Network Interface | 1 × RJ-45, 10/100/1000 Mbps self-adaptive Ethernet interface |
PoE
| Feature | Specification |
|---|---|
| PoE Interface | 16 × RJ-45, 10/100 Mbps self-adaptive Ethernet interfaces |
| PoE Power | ≤ 200 W |
| PoE Standard | IEEE 802.3af/at |
Auxiliary Interface
| Feature | Specification |
|---|---|
| SATA Interface | 4 SATA interfaces |
| HDD Capacity | Up to 16 TB per HDD |
| Serial Interface | 2 × RS-485 (half-duplex), 1 × RS-232 |
| Alarm Input/Output | 16 inputs / 4 outputs |
| USB Interface | Front panel: 2 × USB 2.0; rear panel: 1 × USB 3.0 |
General
| Feature | Specification |
|---|---|
| GUI Languages | English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Hebrew, Ukrainian, Indonesian |
| Power Supply | 200–240 VAC, 50–60 Hz |
| Power Consumption | ≤ 50 W (without HDD) |
| Operating Temperature | −10°C to 55°C (14°F to 131°F) |
| Operating Humidity | 10%–90% |
| Dimensions (W × D × H) | 440 × 391 × 72 mm (17.32 × 15.39 × 2.81 in) |
| Weight | ≤ 5 kg (11 lb), without HDD |
Note: Specifications have been grammatically corrected and standardized for product listing use. Please verify the decoding capability figures and the original manufacturer’s terminology before publication.
