Description
SPECIFICATIONS
Printer Type
Printer Type:
Print, Scan, Copy, Fax with ADF
Printing Technology
Printer Method:
PrecisionCore Printhead
Printer Language:
ESC/P-R, ESC/P Raster
Nozzle Configuration:
400 x 1 nozzles Black, 128 x 1 per Colour (Cyan, Magenta, Yellow)
Maximum Resolution:
4800 x 1200 dpi (with Variable-Sized Droplet Technology)
Automatic 2-sided Printing:
Yes (Up to A4)
Print Speed
Photo Default – 10 x 15 cm / 4 x 6 ” *1:
Approx. 69 sec per photo (Border) / 92 sec per photo (Borderless)*2
Draft, A4 (Black / Colour):
Up to 33.0 ppm / 20.0 ppm*2
ISO 24734, A4 Simplex (Black / Colour):
Simplex: Up to 15.5 ipm / 8.5 ipm*2
ISO 24734, A4 Duplex (Black / Colour):
Duplex: Up to 6.5 ipm / 4.5 ipm*2
First Page Out Time from Ready Mode (Black / Colour):
Approx. 9 sec / 15 sec*2
Copy Function
Maximum Copy Size:
Legal
Copy Resolution:
600 x 600 dpi
Max Copies:
99 copies
Copying
ISO 29183, A4 Simplex Flatbed (Black / Colour):
Up to 11.0 ipm / 5.5 ipm
ISO 24735, A4 Simplex ADF (Black / Colour):
Up to 60 sec / 82 sec
Scanning
Scanner Type:
Flatbed colour image scanner
Sensor Type:
CIS
Optical Resolution:
1200 x 2400 dpi
Maximum Scan Area:
216 x 297 mm (8.5 x 11.7 “)
Scanner Bit Depth (Colour):
48-bit input, 24-bit output
Scanner Bit Depth (Grayscale):
16-bit input, 8-bit output
Scanner Bit Depth (Black & White):
16-bit input, 1-bit output
Scan Speed
Flatbed (Black / Colour):
200dpi: 12 sec / 27 sec
ADF Monochrome (Simplex):
200dpi: 5.0 ipm
ADF Colour (Simplex):
200dpi: 5.0 ipm
ADF Specifications
Support Paper Thickness:
64 – 95 g/m2
Paper Capacity:
30 sheets
Fax Function
Type Of Fax:
Walk-up Black-and-white and Colour Fax Capability
Receive Memory / Page Memory:
1.1 MB, Page memory up to 100 pages
Error Correction Mode:
TU-T T.30
Fax Speed (Data Transfer Rate):
Up to 33.6 kbps, Approx. 3 sec/page
Fax Resolution:
Up to 200 x 200 dpi
Transmission Paper Size (Flatbed):
Letter, A4
Transmission Paper Size (ADF):
Letter, A4, 8.5 x 13”, Legal
Receiving Paper Size:
A4, Letter, Legal
Speed Dial / Group Dial:
Up to 60 numbers, 30 groups
Fax Features:
PC Fax (Transmission / Receive), Automatic Redial, Address book, Broadcast Fax (Mono Only), Transmit Reservation, Polling Reception
Paper Handling
Number of Paper Trays:
1
Standard Paper Input Capacity:
Up to 250 sheets of Plain Paper (80 g/m2), Up to 20 sheets of Premium Glossy Photo Paper
Output Capacity:
Up to 30 sheets of Plain Paper (80 g/m2), Up to 20 sheets of Premium Glossy Photo Paper
Maximum Paper Size:
215.9 x 1200 mm
Paper Sizes:
Legal (8.5 x 14″), 8.5 x 13″, Letter, A4, B5, A5, A6, Hagaki (100 x 148 mm), 16K (195 x 270 mm), Indian-Legal (215 x 345 mm), B6, 5 x 7″, 4 x 6″, Envelopes #10, DL, C6
Maximum Paper Size:
215.9 x 1200 mm (8.5 x 47.24 “)
Print Margin:
0mm top, left, right, bottom via custom settings in printer driver*3
Mobile and Cloud Solutions
Epson Connect Features:
Epson iPrint, Email Print, Remote Print Driver, Scan to Cloud
Other Mobile Solutions:
Apple AirPrint, Mopria Print Service, Epson Smart Panel
Supported OS and Applications
Operating System Compatibility:
Windows XP SP3 / XP Professional x64 SP2 / Vista / 7 / 8 / 8.1 / 10
Windows Server 2003 /2008 / 2012 / 2016 / 2019
Only printing and scanning functions are supported for Windows Server OS
Mac OS X 10.6.8 or later
Noise Level
PC Printing/ Premium Glossy Photo Paper
Best Photo:
Sound Power (Black / Colour) 5 / 5 B(A)
Sound Pressure (Black / Colour) 37 / 38 dB(A)
PC Printing / Plain Paper Default*4:
Sound Power (Black / Colour) 6.9 / 6.4 B(A)
Sound Pressure (Black /Colour) 56 / 52 dB(A)
Dimensions and Weight
Dimensions (W x D x H):
375 x 347 x 231 mm
Weight:
6.7 kg
Consumables
Black Ink Bottle:
Page Yield*5: 7,500 Pages
Order Code: 001 (C13T03Y100))
Cyan Ink Bottle:
Page Yield*5: 6,000 Pages (Composite Yield)
Order Code: 001 (C13T03Y200)
Magenta Ink Bottle:
Page Yield*5: 6,000 Pages (Composite Yield)
Order Code: 001 (C13T03Y300)
Yellow Ink Bottle:
Page Yield*5: 6,000 Pages (Composite Yield)
Order Code: 001 (C13T03Y400)
Electrical Specifications
Rated Voltage:
AC 220-240 V
Rated Frequency:
50-60 Hz
Operating:
12 W
Sleep:
0.9 W
Power Off:
0.2 W
Standby:
5.4 W
Interface
USB:
USB 2.0
Network:
Ethernet, Wi-Fi IEEE 802.11b/g/n, Wi-Fi Direct
Network Protocol:
TCP/IPv4, TCP/IPv6
Network Management Protocols:
SNMP, HTTP, DHCP, BOOTP, APIPA, PING, DDNS, mDNS, SLP, WSD, LLTD
Printer Software
Printer Software:
Epson ScanSmart
Control Panel
LCD Screen:
2.4 ” Colour Touch LCD Screen
