Description
SPECIFICATIONS
Printer Type
Printer Type:
Print, Scan, Copy, Fax with ADF
Printing Technology
Printer Method:
PrecisionCoreTM Printhead
Minimum Ink Droplet Volume:
3.8 pl
Print Direction:
Bi-directional printing
Nozzle Configuration:
800 x 1 nozzles Black, 256 x 1 nozzles per colour (Cyan, Magenta, Yellow)
Maximum Resolution:
4800 x 2400 dpi
Automatic 2-sided Printing:
Yes (up to A3)
Print Speed
Photo Default – 10 x 15 cm / 4 x 6 ” *1:
Approx. 43 sec per photo (Border) / 52 sec per photo (Borderless)*2
Draft, A4 (Black / Colour):
Up to 32.0 ppm / 22.0 ppm *2
ISO 24734, A4 Simplex (Black / Colour):
Up to 25.0 ipm / 12.0 ipm *2
ISO 24734, A4 Duplex (Black / Colour):
Up to 16.0 ipm / 9.0 ipm *2
ISO 24734, A3 Simplex (Black / Colour):
Up to 13.5 ipm / 6.0 ipm *2
ISO 24734, A3 Duplex (Black / Colour):
Up to 10.0 ipm / 5.0 ipm *2
Copy Function
Reduction / Enlargement:
25 – 400%
Maximum Copy Size:
A3
Copy Resolution:
600 x 600 dpi
Max Copies:
999 copies
Copying
ISO 29183, A4 Simplex Flatbed (Black / Colour):
Up to 23.0 ipm / 10.0 ipm
ISO 24735, A4 Simplex ADF (Black / Colour):
Up to 22.5 ipm / 10.0 ipm
ISO 24735, A4 Duplex ADF (Black / Colour):
p to 15.5 ipm / 7.5 ipm
Scanning
Scanner Type:
Flatbed colour image scanner
Sensor Type:
CIS
Optical Resolution:
1200 x 2400 dpi
Maximum Scan Area:
297 x 431.8 (mm)
Scanner Bit Depth (Colour):
48-bit input, 24-bit output
Scanner Bit Depth (Grayscale):
16-bit input, 8-bit output
Scanner Bit Depth (Black & White):
16-bit input, 1-bit output
Scan Speed
Scan Speed (Flatbed / ADF (Simplex | Duplex)):
200dpi, Black: 5 sec / Up to 26.0 ipm | 11.5 ipm
200dpi, Colour: 10 sec / Up to 9.0 ipm | 6.0 ipm
ADF Specifications
Support Paper Thickness:
64-95 g/m2
Paper Capacity:
50 sheets
Fax Function
Type Of Fax:
Walk-up Black-and-white and Colour Fax Capability
Receive Memory / Page Memory:
6MB, Page memory
Up to 550 pages
Error Correction Mode:
ITU-T T.30
Fax Speed (Data Transfer Rate):
Up to 33.6 kbps, Approx. 3 sec/page
Fax Resolution:
Up to 200 x 200 dpi
Transmission Paper Size (Flatbed):
A5, A4, A3, B5, B4, Half Letter, Letter, Legal, 11 x 17″
Transmission Paper Size (ADF):
A5, A4, A3, B5, B4, Half Letter, Letter, Legal, 11 x 17″
Receiving Paper Size:
Half Letter, A5, B5, A4, Letter, Legal, B4, 11 x 17”, A3, A3+
Speed Dial / Group Dial:
Up to 200 numbers, 199 groups
Fax Features:
PC Fax (Transmission/Receive), Automatic Redial, Address book, Broadcast Fax (Mono Only), Transmit Reservation, Polling Reception, Fax Preview, Memory reception, Fax to Email, Fax to Folder, Automatic 2-sided Fax
Paper Handling
Paper Feed Method:
Friction feed
Number of Paper Trays:
3 (Front 2, Rear 1)
Standard Paper Input Capacity:
Cassette 1: 250 sheets for A4 Plain paper (80g/m2)
50 sheets for Premium Glossy Photo Paper
Cassette 2: 250 sheets for A4 Plain paper (80 g/m2)
Rear Slot: 50 sheets for A4 Plain paper (80 g/m2), 20 sheets for Premium Glossy Photo Paper
Output Capacity:
125 sheets for A4 Plain paper (80 g/m2), 20 sheets for Premium Glossy Photo Paper
Maximum Paper Size:
329 x 6000 mm
Paper Sizes:
A3, Super B (13 x 19″), Indian Legal, Letter, A4, 16K (195 x 270mm), 8K (270 x 390mm), Executive (7.25 x 10.5″), B4, B5, A5, B6, A6, 8.5 x 13″, 5 x 7″, 4 x 6″, 8 x 10″, Legal (8.5 x 14″), 16:9 wide, Envelopes: #10, DL, C6, C4
Print Margin:
3mm top, left, right, bottom via custom settings in printer driver
Card Slot / USB Host Function
Type of Direct Printing:
USB Memory
Mobile and Cloud Solutions
Epson Connect Features:
Epson iPrint, Epson Email Print, Remote Print Driver, Scan to Cloud
Other Mobile Solutions:
Apple AirPrint, Mopria Print Service
Supported OS and Applications
Operating System Compatibility:
Windows XP / Vista / 7 / 8 / 8.1 / 10, Windows Server 2003 / 2008 / 2012 / 2016 / 2019
Mac OS X 10.6.8 or later
Noise Level
PC Printing / Plain Paper Default *3:
Sound Power (Black / Colour) 6.7 B(A) / 6.2 B(A), Sound Pressure (Black / Colour) 52 dB(A) / 47 dB(A)
Dimensions and Weight
Dimensions (W x D x H):
515 x 500 x 350mm
Weight:
20.7kg
Consumables
Maintenance Box:
C12C934591
Pigment Black Ink Bottle:
7,500 pages *4 – 008 (C13T06G100 / C13T06G199 (Indonesia))
Pigment Cyan Ink Bottle:
6000 pages (Composite Yield) *4 – 008 (C13T06G200 / C13T06G299 (Indonesia))
Pigment Magenta Ink Bottle:
6000 pages (Composite Yield) *4 – 008 (C13T06G300 / C13T06G399 (Indonesia))
Pigment Yellow Ink Bottle :
6000 pages (Composite Yield) *4 – 008 (C13T06G400 / C13T06G499 (Indonesia))
Interface
USB:
USB 2.0
Network:
Ethernet, Wi-Fi IEEE 802.11 b/g/n, Wi-Fi Direct
Network Protocol:
TCP/IPv4, TCP/IPv6
Network Management Protocols:
SNMP, HTTP, DHCP, BOOTP, APIPA, PING, DDNS, mDNS, SNTP, SLP, WSD, LLTD
Power
Rated Voltage:
AC 220 – 240 V
Rated Frequency:
50 – 60 Hz
Power Consumption:
Operating: 19.0 W
Standby: 9.1 W
Sleep: 0.8 W
Power off: 0.2 W
Printer Software
Printer Software:
Epson ScanSmart
Control Panel
LCD Screen:
4.3″ Colour LCD Touch Screen
