Description
SPECIFICATIONS
| Model Number | Black: MF500M-KHNN-S01 (ARGB)
Silver: MF500M-SHNN-S01 (ARGB) |
| Color (s) | Black / Silver |
| Materials – Exterior | SGCC Steel, Aluminum |
| Material – Side Panel (Right / Left) | Tempered Glass |
| Dimensions (L x W x H) | 471 x 261 x 544mm (Incl. Protrusions), 471 x 244 x 514mm (Excl. Protrusions)471 x 261 x 544mm (Incl. Protrusions), 471 x 244 x 514mm (Excl. Protrusions) |
| Volume | 60.9 L (Excl. Protrusions) |
| Motherboard Support | Mini-ITX, Mini-DTX, Micro-ATX, ATX , E-ATX*, SSI-CEB* ​(*Conditional Support) |
| PCI Expansion Slots | 8 |
| 3.5″ Drive Bays | 0 |
| 2.5″ / 3.5″ Drive Bays (Combo) | 1 (Bottom) |
| Preinstalled Drive Bays – 3.5″ / 2.5″ Drive Bay (or SSD) (remark Toolfree quantity) | 1x 2.5 or 1x 3.5 |
| I/O Panel – USB Ports | 2x USB 3.2 Gen 1 Type A, 1x USB 3.2 Gen 2×2 Type C |
| I/O Panel – Audio In / Out | 1x 3.5mm Headset Jack (Audio+Mic) |
| Pre-installed Fans – Front | 2x SickleFlow 200mm ARGB |
| Pre-installed Fans – Side Rear | 1x 120mm ARGB |
| Fan Support – Front | 3x 120mm, 2x 140mm, 2x 180mm, 2x 200mm |
| Fan Support – Top | 3x 120mm, 2x 140mm, 2x 180mm, 2x 200mm |
| Fan Support – Rear | 1x 120mm |
| Fan Support – Bottom | 1x 120mm |
| Radiator Support – Front | 120 / 140 / 240 / 280 / 360mm |
| Radiator Support – Top | 120 / 140 / 240 / 280 / 360mm |
| Radiator Support – Rear | 120mm |
| Dust Filters | Mesh Only (Removable Filters) |
| Clearance – CPU Cooler | 190mm |
| Clearance – PSU | 235mm |
| Clearance – Graphics Card | 390mm |
| Power Supply Support | ATX |
| Included Accessories | GPU Support Bracket |
| Cable Routing – Behind Motherboard Tray | 43 mm |
| Series | MasterFrame Series |
| Size | Mid Tower |
