Description
SPECIFICATIONS
| Model Number | MasterBox 600 Black:MB600-KGNN-S00
MasterBox 600 White:MB600-WGNN-S00 |
| Color (s) | Black / White |
| Materials – Exterior | Steel, Plastic |
| Material – Side Panel | Tempered Glass |
| Dimensions (L x W x H) | 474 x 230 x 481mm (Incl. Protrusions), 465 x 230 x 465mm (Excl. Protrusions) |
| Volume | 49.73L |
| Motherboard Support | ITX / Micro ATX / ATX (Supporting Back-connector Motherboard) / E-ATX (*up to 12″x10.9″ / 30.5cmx27.7cm motherboards, may impact cable management) |
| PCI Expansion Slots | 7 |
| 3.5″ Drive Bays | 2 |
| 2.5″ Drive Bays | 2 (Max.6) |
| I/O Panel – USB Ports | 2x USB 3.2 Gen 1 Type A, 1x USB 3.2 Gen 2×2 Type C |
| I/O Panel – Audio In / Out | 1x 3.5mm Combo |
| Included Accessories | ARGB Fans Hub |
| Pre-installed Fans – Front | 3x 140mm SickleFlow140 ARGB PWM (650~1800 rpm) |
| Pre-installed Fans – Rear | 1x 120mm CF120 ARGB (650~1200 rpm) |
| Fan Support – Front | 3x 120/140mm |
| Fan Support – Top | 3x 120mm / 2x 140mm |
| Fan Support – Rear | 1x 120mm |
| Radiator Support – Front | 120 / 140 / 240 / 280 / 360 / 420mm (Limit: 457*140*27mm) |
| Radiator Support – Top | 120 / 140 / 240 / 280 / 360mm |
| Radiator Support – Rear | 120mm |
| Clearance – CPU Cooler | 170mm |
| Clearance – PSU | 170mm, 210mm (w/o HDD Cage) |
| Clearance – GFX | 360mm, 410mm (w/o front radiator) |
| Power Supply Support | ATX |
| Dust Filters | Top, Bottom |
| Cable Routing – Behind Motherboard Tray | 33-35 mm |
| Series | MasterBox Series |
| Size | Mid Tower |
| Back Connector Motherboard Support | Yes |
