Description
SPECIFICATIONS
| Model Number | Black: E490-KHNN-S00 White: E490-WHNN-S00 |
| Exterior Color (s) | Black / White |
| Materials – Front Panel | Tempered Glass |
| Material – Side Panel (Left) | Tempered Glass |
| Material – Side Panel (Right) | Steel |
| Dimensions (L x W x H) | 434 x 218 x 414 mm (Incl. Protrusions), 430 x 218 x 395 mm (Excl. Protrusions) |
| Volume | 39.16 L (Liters Incl. Protrusions) |
| Motherboard Support | ITX / Micro ATX |
| Expansion Slots | 5 |
| 3.5″ Drive Bays | 1 (Max. 2) |
| 2.5″ Drive Bays | 1 |
| I/O Panel – USB Ports | 1 x USB Type C 20Gbps, 2 x USB 3.0 |
| I/O Panel – Audio In / Out | 1x 3.5mm Combo |
| Pre-installed Fans – Rear | 1x 120mm ARGB PWM |
| Pre-installed Fans – Side Mount | 2x 120mm ARGB PWM reverse fan |
| Fan Support – Top | 2x 140mm / 3x 120mm |
| Fan Support – Rear | 1 x 120mm |
| Fan Support – Side Mount | 2x 120mm |
| Fan Support – Bottom | 3x 120mm |
| Radiator Support – Top | 120 / 240 / 360 (Max height 45mm) |
| Radiator Support – Bottom | 120 / 240 / 360mm |
| Radiator Support – Side Mount | 120 / 240mm |
| Clearance – CPU Cooler | 170mm |
| Clearance – PSU | 250mm |
| Clearance – Graphics Card | 425mm |
| Power Supply Support | ATX |
| Series | Elite Series |
| Size | Mini Tower |
