Description
| Specifications | |
|---|---|
| General | |
| Model | PRIME-750B-BLACK |
| Intel Form Factor | ATX12V |
| ATX Standard | NA |
| PFC Type | Active PFC |
| Efficiency | 80 PLUS Bronze |
| Total Output | 750W |
| Dimensions | 150 × 150 × 86 mm |
| MTBF | >120,000 hours @ 25°C |
| Hazardous Materials | RoHS |
| 0dB Technology | No |
| Cybenetics Noise Level Certification | NA |
| Protection Features | |
| Protection Features | OPP / OVP / UVP / SCP / OCP / OTP |
| Input & Output | |
| AC Input Range | 100–240Vac |
| DC Output Voltage | +3.3V / +5V / +12V / -12V / +5Vsb |
| Maximum Load | |
| +3.3V | 20A |
| +5V | 20A |
| +12V | 62.5A |
| -12V | 0.3A |
| +5Vsb | 2.5A |
| Combined Load | |
| +3.3V | 120W |
| +5V | 120W |
| +12V | 750W |
| -12V | 3.6W |
| +5Vsb | 12.5W |
| Cable Connectors | |
| Motherboard | 24/20-pin × 1 |
| CPU | 4+4-pin × 2 |
| PCI-E | 8-pin × 3 |
| SATA | × 6 |
| Peripheral | × 3 |
| Package Contents | |
| Power Cord | × 1 |
| Motherboard Power Cable | × 1 (600 mm) |
| CPU Cable | × 2 (800 mm) |
| PCI-E 1-to-2 Cable | × 1 (600 mm) |
| PCI-E 1-to-1 Cable | × 1 (600 mm) |
| SATA 1-to-3 Cable | × 2 (400 + 120 + 120 mm) |
| Peripheral 1-to-3 Cable | × 1 (400 + 120 + 120 mm) |
| User Manual | × 1 |
| Weight | |
| Single PSU | 2.2 kg |
| Product Weight with Packing | 3.067 kg |
