Description
| General Specifications | |
|---|---|
| Operating Ambient Temperature | 0–40 °C |
| Dimensions | 120 × 120 × 27 mm |
| Net Weight | 172 g |
| Fan Specifications | |
| Fan Speed | 500–3000 RPM, PWM Controlled |
| Zero RPM Mode | 0 RPM below 5% PWM |
| Airflow | 73 CFM / 124 m³/h |
| Static Pressure | 4.5 mmHâ‚‚O |
| Fan Bearing | Fluid Dynamic Bearing |
| Typical Voltage | 12 V DC |
| Start-Up Voltage | 3.5 V DC |
| Current | 0.4 A |
| Cable Length | 400 mm + 80 mm Daisy-Chain Cable |
| Connector | 4-Pin Fan Plug + 4-Pin Socket |
