Description
SPECIFICATIONS
| MODEL NAME | SP850 |
|---|---|
| MODEL NO. | SP850 BLACK / SP850 WHITE |
| DIMENSIONS | (D)100 mm X (W)63.5mm X (H)125 mm |
| POWER SUPPLY DESIGN | Fully modular |
| COLOR | Black / White |
| MATERIAL | Steel/brushed aluminum housing |
| FORM FACTOR | SFX |
| CERTIFICATION | 80 PLUS Gold |
| POWER SUPPLY DESIGN | Fully modular |
| MAX. DC OUTPUT | 850W |
| COMBINED +3.3V & +5V | 100W |
| COMBINED +12V | 840W |
| INPUT VOLTAGE | 100-240Vrms |
| INPUT FREQUENCY RANGE | 50Hz-60Hz |
| PFC | Active PFC(PF)>0.90 at full load |
| EFFICIENCY | 93.53% MAX |
| PROTECTIVE CIRCUIT | OCP OVP OTP OPP SCP UVP |
| CONNECTORS | 1 x 24/20-Pin motherboard connector (300mm) x1pcs 1 x 8/4+4 Pin CPU/ATX 12V connector (600mm) x2pcs 1 x 8/6+2 Pin PCle connector (400mm) x1pcs 2 x 8/6+2 Pin PCle connector (400mm-120mm) x1pcs 4 x SATA connector (120mm120mm-120mm-120mm) x2pcs 4 x 4-Pin Peripheral connector (120mm-120mm-120mm- 120mm) x1pcs 12VHPWR connector (400mm) × 1pcs |
| NOISE LEVEL | 17.1-40.6DBA |
| FAN RPM | 1000-2800 RPM |
| BEARING TYPE | HYB |
